Resilient Replaceable Seat Butterfly Valve

Designed for reliable shutoff and long service life, the Resilient Seat Butterfly Valve is ideal for general-purpose flow control in water, HVAC, and industrial applications. Featuring a replaceable seat and various actuation options, it ensures maintenance ease and operational efficiency.

Key Specifications

• Type: Resilient Replaceable Seat
• Size Range: 50 mm to 600 mm (2" to 24")
• Body Material: Cast Iron, Ductile Iron, WCB (Wafer & Lug type)
• Disc Material: Ductile Iron (Nylon/Aroxy Coated), CF8, CF8M
• Seat Material: Buna N, EPDM, Viton®, Silicone (FDA Compliant)
• Stem Material: SS410, SS316, Carbon Steel + Zinc Plated
• Operation Modes: Lever, Gearbox, Pneumatic Actuator, Electric Actuator
• Temperature Range: –40°C to +200°C
• Pressure Rating: PN10 / PN16

This valve offers versatility in installation and reliable performance for both on/off and throttling duties across various fluid handling systems.

Resilient Seat Butterfly Valve (Large Diameter)

Engineered for durability and reliability, the Resilient Seat Butterfly Valve with a large diameter configuration is designed to meet the requirements of high-volume flow systems. Suitable for a wide range of industrial and utility applications, it features a replaceable seat, corrosion-resistant construction, and multiple actuation options for enhanced performance and flexibility.

Key Specifications

• Type: Resilient Replaceable Seat Butterfly Valve
• Size Range: 50 mm to 600 mm (2" to 24")
• Body Material: Cast Iron, Ductile Iron, WCB (Wafer & Lug Type)
• Disc Material: Ductile Iron (Nylon / Aroxy Coated), CF8, CF8M
• Seat Material: Buna N, EPDM, Viton®, Silicone (FDA Compliant)
• Stem Material: SS410, SS316, Carbon Steel with Zinc Plating
• Operation Options: Lever, Gearbox, Pneumatic Actuator, Electric Actuator
• Temperature Range: –40°C to +200°C
• Pressure Rating: PN10 / PN16

This valve offers robust construction and efficient flow control, making it ideal for water treatment plants, HVAC systems, fire protection, and various industrial services.

Triple Offset Soft & Metal Seated Butterfly Valve

Engineered for high-performance industrial applications, our Triple Offset Butterfly Valves deliver precise flow control with superior sealing capabilities. Available in both soft and metal seated variants, these valves are designed to perform reliably under extreme pressure and temperature conditions.

Key Specifications

Type: Triple Offset – Soft & Metal Seated

Size Range: 50 mm to 1000 mm (2" to 40")

Body Material Options: WCB, CF8, CF8M, CF3, CF3M, LCB, CA15

Disc Material Options: WCB, CF8, CF8M, CF3, CF3M, LCB, CA15

Seat Type: SS316 + Graphite / Full Metal

Stem Material: 17-4-PH SS (ASTM A564 Type 630) / SS410 (ASTM A479)

Operation Modes: Manual (Lever/Gearbox), Pneumatic Actuator, Electric Actuator

Temperature Range:

Soft Seated: –40°C to +200°C

Metal Seated: –100°C to +400°C

Pressure Rating: ASME Class 150 / 300 / 600 / 900 / 1500 / 2500
