Volume Booster
| PRODUCT TYPE | Volume booster |
| Max Supply Pressure | Must be same as final control device. Upto 40 psig normally used with diaphragm actuators. Upto 150 psig normally used with piston actuators |
| Dead band Width | 1 psi or 5% of outspan, whichever is greater |
| Port Connections | 1/4" or 3/8" NPT, 1/2" or 3/4" NPT |
| Flow Capacity | 13.5 scfm (22.95 m³/hr), 115 scfm (195.4 m³/hr) |
| Maximum Cv | 1.02, 3.0 |
| Temperature Range | -20°C to 70°C |
Functions
- Air Flow Amplification
- Pressure Matching
- Supply & Exhaust Control
- Deadband Sensitivity
Applications
- Process Control Valves:
- Power Plants
- Water Treatment
- HVAC Systems
- Robotics & Automation.
Benefits
- Faster Actuator Response
- Improved Control Accuracy
- Energy Efficiency
- System Stability
- Safety Assurance
