| Application | Most suitable for pressure tight shut-off for water, sea water, mild slurry, liquid-solid mixes and dry bulk solid applications. |
| Flow Direction | Uni-directional |
| Available sizes | DN 50 (2”) to DN 1200 (48”) |
| Pressure rating | PN3 (45 PSI), PN6 (90 PSI), PN10 (150 PSI), PN16 (232 PSI) depending upon housing material, primarily for liquid applications. |
| Temperature suitability | -20°C to 250°C |
| Seating | Resilient seat (Replaceable metal ring as an option.) |
| Bonnet | Bolt on type (Optional) |
| Flange drilling standard | ASME B16.5/ASME B16.47 #150 / BS-EN 1092 PN 10 / PN 16 |
| Mode of operations | Manual, chain wheel, pneumatic, electric actuator and Hydraulic |
